EAN code8595057634923
Customs code85363030
Weight0.02 kg/pcs
Halogen free materialyes
Leadless materialyes
Self-extinguishing30 s
Rated voltage<= 400 V
Rated current<= 16 A
Temperature resistance-20 - 80 °C
Flaming loop test850 °C
Diameter73 mm
Depth30 mm
Fire reaction classA1 - D
Possibility to connect 2 boxes in a seriesyes
StandardsČSN EN 60 670-1
Package description
packed in shrink foil, label marked, screws including

For premises with increased need for protection of persons and property. Cylindrical head screws Ø 2.9 x 6.5 mm are used to fasten the devices. Countersunk screws Ø 2.9 x 9.5 mm are used to fasten the V 68HF cover.
