EAN code8595568939258
Customs code73269098
Weight0,0387 kg/pcs
Surface finishZn+Mg+Al galvanizing
Temperature resistance-50 - 150 °C
Funcionality in fireP90-R, E90, PS90
StandardsČSN EN 61537
Fire resistance standardsČSN 73 0895, DIN 4102-12, STN 92 0205
Thickness of metal sheet1 mm
Quantity of screws for connecting2
Dimension H47 mm
For width of cable tray62 - 250 mm
For height of cable tray50 mm

The joining is performed using the bolts NSM 6X10.

Note for system with maintained functionality in fire:
You find more information in the catalogue Systems with maintained functionality in fire.
